 |5m 5 Seats Kingwin Ambulance Van
Kingwin Ambulance Van

5m 5 Seats Kingwin Ambulance Van

5 Seats ambulance van is a car specially designed for medical institutions, to gain more time for patients to go to treatment, independent design team, free visual program design, to meet the different needs of customers.

Inquire Now
Product categories
how can we help you
You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.
Contact Us
New Products

In light of the features of first aid and makeshift operation by paramedics, the ambulance is provided with scientific and rational aid space, stretcher, oxygen cylinder, sterilizing lamp, 220V continuous power supply equipment, and other first aid equipment so as to achieve mobile medical aid.

5m Ambulance Van5 Seats Ambulance Van

Length×Width×Height (mm) 5270×1700×2250
Wheelbase (mm) 2890
Seats No. 2 or 5 seats
Body Structure Monocoque body
Engine XG491, 4RB2, 4JB1T
Displacement (L) 2.237L, 2.4L, 2.771L
Max. Power (kW/rpm) 76/4600, 110/4600-5000, 57/3600
Max Torque (N·m/rpm) 193/2800, 217/2600-3200, 172/2000
Transmission 5MT
Suspension Front independent torsion bar spring, rear five leaf spring suspension
Brake System Front disc/rear drum
Assistant Braking System Load proportional valve, ABS+EBD
Tyre 195/70R15C
Optional Configurations 2 seats with gray PU in the driver cabin
Medical cabin's seats with red PU
Alarm light & alerter
Interphone
Rear and side glass window with film
Airtight middle baffle with inspection window
Fiberglass roof
Work light in medical area
2x10L oxygen cylinder with 2 oxygen pressure gauges
Infusion bottle hook 2 pcs
Electric suction apparatus
Medical cupboard
Blood pressure gauge
Trash can with cover
Automatic loading stretcher
Medical floor leather
Ultraviolet rays sterilization lamp
Intake & exhaust fresh air system
Rear reflector light
Power inverter system with 2 AC sockets & 1 DC socket
Hot Tags : Kingwin Ambulance Van 5m Ambulance Van 5 Seats Ambulance Van 5m 5 Seats Ambulance Van
